製品情報
| 原産地: 中国(本土) | 銘柄: OWIRE/APKTE/OEM | モデル番号: Cat6 UTP Network Cable |
| タイプ: 猫6 | コンダクターの数: 8 |
包装
| 包装: 1000ft(305m)/carton 305m/carton, 2cartons/box 950 carton/20ft container 2100 carton/40HQ (can design according to customer requirement) |
仕様
Cat6 network cable 1.FLUKE/CE/ISO/ROHS/TLC 2.Waterproof Cat6,Outdoor Use 3.Factory,OEM/ODM available
Cat6 UTP Network Cable
Cable Assembly Specification for Your Reference:
Conductor | Insulation | Core Number | Filler | Jacket | ||||
AWG | Specification (mm) | Material | Thickness (NOM.mm) | Material | Thickness (NOM.mm) | OD (NOM.mm) | ||
26 | 1/0.404 | HD-PE | 0.18 | 4P | PE Cross | PVC or LSNH | 0.55 | 5.5 |
7/0.16 | HD-PE | 0.18 | 4P | PE Cross | PVC or LSNH | 0.55 | 5.5 | |
24 | 1/0.58 | HD-PE | 0.18 | 4P | PE Cross | PVC or LSNH | 0.55 | 6.5 |
1/0.58 | HD-PE | 0.18 | 4P | FM-PE Thin slice | PVC or LSNH | 0.55 | 6.0 | |
7/0.203 | HD-PE | 0.18 | 4P | PE Cross | PVC or LSNH | 0.55 | 6.2 | |
7/0.203 | HD-PE | 0.18 | 4P | FM-PE Thin slice | PVC or LSNH | 0.55 | 5.8 | |
Structure:
Owire brand, OEM/OEM network cable, fiber optic cable manufacturer, factory in Shenzhen, China.
