| 原産地: | 中国(本土) | 銘柄: | jowell | モデル番号: | ZWJT-3A | テーブルトップ: | sus304 | 仕上げ: | パウダーコーティングされた | 電源: | 220ボルト50/60ヘルツ |
包装
| 包装: | 合板および木枠 |
Clean Equipments Laminar Flow Cabinet Biosafety Cabinet
Features:
1. Cleanliness: Class100, conformed to International standard;
2. Horizontal and open type, easy operation;
3. Adopting changeable airflow control and low noise system, to make working area keep in ideal condition;
4. Clean bench case is electrostatic powder coated plate that is shining and neat; SS304 is used as working table.
5. Material: Cold rolled steel plate with powder coated or stainless steel (SS201 or SS304).
Model | ZK-1000 | ZK-1350 | ZK-1610 | ZK-1915 |
External size(mm) | W1000*L740*H1460 | W1350*L740*H1460 | W1610*L740*H1460 | W1915*L740*H1460 |
Internal working size(mm) |
W980*L480*H610 |
W1285*L480*H610 |
W1590*L480*H610 |
W1895*L480*H610 |
Air flow(m/h) | 900 | 1200 | 1500 | 1800 |
wind velocity | 0.45m/s±20% | |||
Cleanliness class | Class 100 (ISO14644-1 International standard) | |||
Mini-pleat Hepa Filter | 99.99% @ 0.3μm | |||
Size & NO. of Hepa Filter |
915*610*69-1 |
1220*610*69-1 | 915*610*69-1 610*610*69-1 |
915*610*69-2 |
Table material | SS304 | |||
Noise | <50 dB | <50 dB | <50 dB | <50 dB |
Noise testing area | The area 20cm away from the front of clean bench and 1.2 m height. | |||
Power | AC, 220V 50/60Hz | |||
Used for NO. of people |
1 |
1-2 |
2-3 |
3-4 |
