| 原産地: | 中国(本土) | 銘柄: | jiazhao | モデル番号: | JZ-5K/8K-TY | 入力電圧: | 380ボルト50/60 mhz | 次元: | 1.5*1.6*2.5メートル | 使用法: | を押すと、溶接、切断、など | 溶接圧力: | 5〜18 t、10〜18 t、10〜20 t | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | タイプ: | ブリスター包装機 | 駆動型タイプ: | 空気圧 | アプリケーション: | 化学、機械&ハードウェア、アパレル | 溶接時間: | 0〜10 s調節可能 | 発振チューブ: | 7T85RB、7T69RB、E3069RB | 電極間隔: | 0〜170ミリメートル | プレスストローク: | 50ミリメートル | 周波数: | 27.12 mhz | 整流: | シリコンダイオード | 温度範囲: | 0〜200℃ |
包装
| 包装: | 標準的な輸出木製ケース |
Model | JZ-5K-TR(Y) | JZ-8K-TP(Y) | JZ-10K-TR(Y) |
High frequency power | 5KW | 8KW | 10KW |
Oscillation tube | 7T85RB | 7T69RB | E3069RB |
Biggest pressure | 5~18T | 10~18T | 10~20T |
Electrode spacing | 0~170mm | ||
Press stroke | 50mm | ||
Upper plate size | 250*400mm | ||
Lower plate size | 350*500mm | ||
Supply voltage | 380V 50/60HZ | ||
Frequency | 27.12MHZ | ||
Power input | 8KVA | 15KVA | 18KVA |
Rectifier | Silicon diode | ||
Temp range | 0~200°C | ||
Station | Two | ||
Operation mode | Hydraulic or foot step type | ||
Welding time | 0~10s adjustable | ||
Physical size | 1.5*1.6*2.5m | ||
High ferequency heat sealing,packing sealing cutting edge.
PVC, environmental protectio PET,( APET,PETG, HPET,GAG,etc. )
Clothing, textiles, toys, medicine, hardware, machinery, gifts, arts and crafts
Anti radio interference device:
Stable welding frequency
High output power and reliable performance
Safe performance: high sensitivity spark arrester.
Packaging & Shipping
1.Standar export wooden case.
2.7-30 working days, depends on quantity and the products.
Our Services
Pre-sale services:
1.Provide professional technical support.
2.Send the product catalog and instruction manual.
3.Answer your question within one working day,you can contact us online or send us email.
4.Personal call or visit is warmly welcome.
Sale of services:
1.We promise honest and fair, it is our pleasure to serve you as you purchasing our consultant.
2.We guarantee punctuality,quality and quantities strictly implement the terms of contract.
After-sale service:
1.wher to buy our products for one year warranty and long maintenance.
2.24 hours telephone service online.
3.A large stock of components and parts, easily-worn parts.
