原産地: | 中国(本土) | 銘柄: | hl左官工事のマシン | モデル番号: | Hl60r-w | 重量: | 650キロ | 自動等級: | 自動 | 力(W): | 21 | 保証: | 1年 | 条件: | 新しい | 認証: | ce | 次元(L*W*H): | 2850*1220*1080mm | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | アプリケーション: | 配達、 ボンディングおよび左官工事 | モデル番号: | 新技術hl60r-w壁の左官工事のマシン | 寸法( l*w*h): | 2850*1220*1080mm | 重量: | 650キロ | 認証: | iso9001 | 保証: | 6ヶ月 | 後- セールスサービスが提供される:: | 海外三- パーティー利用可能なサポート | 色: | オプション |
包装
包装: | 木製カートン、 パッキングすることも可能あなたの条件に従って |
2015 new products China good quality electric cement grout injection pump price
Product Description
New technology wall plastering machine
HL60R-W is the combined machine introduced German technology. It's applied for construction of various characteristics and use of dry ready-mixed mortar. It’s driven by the internal combustion engine with strong and stable power. Adopts advanced hydraulic system with reliable working. It can adjust working pressure, output and mixing speed freely. It has functions combined functions of mixing, pumping, bonding and plastering. It's easy to operate and move with traction driving.
Technical parameters of JP60R-W Mortar plastering machine
Model
| — | HL60R-W |
Supply power
| — | Diesel engine |
Engine power
| kw | 21 |
Maximum grain size
| mm | 4 |
Output
| L/min | 40 |
Delivery pressure
| bar | 30 |
Horizontal delivery distance
| m | 100 |
Vertical delivery distance
| m | 50 |
Mixer volum
| L | 200 |
Hopper volume
| L | 200 |
Net weight
| kg | 650 |
Dimension (L×W×H)
| mm | 2850×1220×1080 |
