| 原産地: | 中国(本土) | 銘柄: | rehoo | ドライブの種類: | 電気 | 適用: | 食物 | モデル番号: | Cwm-220 | 自動等級: | 自動 | 包装材料: | プラスチック | 包装タイプ: | パックされた食品 | タイプ: | パッケージライン | 条件: | 新しい | 力: | シングル- 相ac200v~240v | 名: | オンラインチェック計量 |
包装
| 包装: | 木製ケース |
CWM-220 Automatic sorting machine
Technical Data | ||
|
| |
Model | CWM-220 | |
Weighing Capacity | 10~1200g | |
Weighing Accuracy | ± 0.5g | |
Product dimensions | L(mm) W(mm) H(mm) | 30~300 30~220 10~150 |
Weighing Scale Size | 400mm(L)x245mm(W) | |
Weigh Sensor | Double-beam load cell | |
Conveying | Food Belt(Belt Width:220mm) | |
Display | Chinese, English | |
Minimum Scale | 0.1g | |
Setting Range | Weight Value | press the number keys:0.1g~1200.0g(standard +Over:0.1g difference) |
Belt speed | Standard weight setting:15~60m/min(1m/min spacing) | |
Menu | Standard/Over/Under weight, product name, belt speed etc pre-setting as one unit; Totally 50 units | |
Error Message display | Zero error,photosensor error,setting error,products too close error,product too long error | |
IP rating | In accordance with international IP65 standard | |
Construction | 304SUS, Polishing | |
Machine Size | L x W | 750mm x 580mm |
The height from conveyor belt to the ground | 650mm~900mm | |
Machine Weight | Appr.55Kg | |
Power Supply | Single-Phase AC200V~240V
| |
Other Standard Accessories | Windshield cover(Colorless and Clear),photosensor | |
