原産地: | 中国(本土) | 電圧: | 380v | 銘柄: | 瀋陽 | モデル番号: | Sy- debarkingマシン | 重量: | 1800キロ | 力(W): | 46キロワット | 認証: | Iso9001-2000 | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | 木製の長さの範囲: | 1300-2600 | 条件: | 新しい | 木製の損失率: | 2% | 皮率: | 99% | 次元(L*W*H): | 3000*2000*1300 | 木製の直径の範囲: | 400mm | 紡錘の速度: | 45m/min | 流量油圧駅: | 32pa/s | 色: | あなたの条件に応じて | 作業方法: | plc | パワー: | 電気 | 鋼: | h | 油圧システム: | シリンダー | 、合板に使用され: | 使用される合板の生産ラインにおける | での作業: | ピーリングマシン |
包装
包装: | よく- pckingコンテナ用 |
plywood machines - Hydraulic wood debarker
Function
-This machine is used to debarking the skin & making round the log before peeling.
Specification
-Maximum peeling length
SX1400 model 1.3meter
SX2700 model 2.6meter (other length required)
-Maximun peeling diameter: 350-400mm
-Remainder diameter:30mm
-Debarking thickness:1-8mm
-Peeling Speed: 45m/min
-Roller diameter: 130mm
-Power: 18.5kw
Main charactor:
-Enlarge single / double Rollers diameter, improve its peeling speed, more efficient.
-Rollers to be chromate treatment, higher wearing resistant and durable.
-Equipment suitable power according experimental mechanics, would save energy cost.
-Knife given follow hydraulic system, given pressure is able to be adjusted and shown, suitable for all kinds log materials.
Pictures below is debarking machine:
If you have any question of this debarking machine and peeling machine, please feel free to contact me.
