| 原産地: | 中国(本土) | 銘柄: | tplcd | モデル番号: | fd * * p01 | タイプ: | タッチスクリーン情報キオスク | パネルサイズ: | 32-82インチ | 解像度: | フルhd 1920*1080 | 明るさ: | 1500-3000nits | 保護ガラス: | ip55 | コントラスト比: | 3000: 1 | 動作温度: | -20 ℃〜+ 40 ℃ | 温度制御システム: | ファン冷却システム | 明るさコントロール: | 自動光センサーシステム | ビデオインタフェース: | vga hdmi |
包装
| 包装: | 木箱の包装、 または包装するために顧客の要求に応じて。 |
| Product Parameters | |||||
| Model | FD42P01 | FD47P01 | FD55P01 | FD65P01 | FD70P01 |
| Size | 42’’ (930*523mm) | 47’’ (1039*584mm) | 55’’(1209*680mm) | 65"(1428*803mm) | 70"(1561 *883mm) |
| Display Ratio | ( 9"16 ) | ||||
| Resolution | 1366*768 | 1920*1080 | 1920*1080 Full HD | 1920*1080 Full HD | 1920*1080 Full HD |
| Brightness | 1500 cd/m² | 1500 cd/m² | 2000 cd/m² | 2000 cd/m² | 2000 cd/m² |
| Contrast Ratio | ( 3000:1 ) | ||||
| Viewing Angle | 178 °/ 178 ° | ||||
| Operation Parameters | |||||
| Video Interface | VGA HDMI | ||||
| Audio Interface | Input and output | ||||
| Brightness Control | Automatic light sensor system | ||||
| Temperature Control System | Fan cooling system | ||||
| Operating Temperature | —20°C to +45°C | ||||
| Operating Humidity | 5% to 100% | ||||
| Power Supply | AC 108-115V / AC 208-240V | ||||
| Max Consumption | 400 W | 600W | 900W | 1300W | 1400W |
| Waterproof Enclosure | |||||
| Protection Grade | IP55 | ||||
| Package Size (W*H*D) | 1900*700*240mm | 1980*765*240mm | 2000*860*240mm | 2100*1000*240mm | 2200*1080*240mm |
| Gross weight | 120kg | 140kg | 180kg | 240kg | 280kg |
| Installation | Free standing | ||||
| Protection Glass | 6mm AR safe glass | ||||
| Optional Configurations | |||||
| Advertising Industry | Network version of embedded decoding play system | ||||
| Professional Display Industry | Embedded PC and information publishing system | ||||
| Touch Screen | IR waterproof anti-glare touch screen | ||||
Application:
1. Commercial Organizations: Supermarket, Shopping mall, Exclusive agency, Chain shops, Department Stores, Hotel, Restaurants, Travel agency, Pharmacy, Convenient stores, Group Headquarter, etc;
2. Financial Organizations: Banks, Negotiable Securities, Funds, Insurance company, Pawnshops, etc;
3. Non-profit Organizations: Telecommunication, Post offices, Hospital, School, etc;
4. Public Place: Subway; Airport, Railway station, Bus station, Gas station, Toll stations, Bookstore, Parks, Exhibition Hall, Stadium, Museums, Convention centers, Ticket offices, Job center, Lottery center, etc;
5. Real Estate Property: Apartments, Villas, Office, Commercial Buildings, Model rooms Property Brokers, etc;
6. Entertainment: Theatre, Fitness Hall, Country Club, Massage Shop, Bars, Cafes, Internet Bars, Beauty shop, Golf course center, etc.
