| 原産地: | 中国(本土) | 銘柄: | shg | モデル番号: | tr- | パッキング: | 木製ボックスまたはwowenバッグ | 証明書: | ce iso9001 2004 ISO4001 2008 | 広告看板: | 三メッセージサイン | モーター: | 120ワットオリジナルパナソニックモータ、。 | 使用法: | 屋外広告 | 共通名: | trivisionまたはtrivision看板またはtrivisionボード | ドライブシステム: | ダブル傘歯車駆動システム | 風の抵抗: | いいえ未満10クラスで自動風抵抗機能、 | 運転コンポーネント: | pa66工業ナイロンとcordura (アメリカデュポン) | 電源: | 220ボルト/ 50 ｈｚ、0.54a |
包装
| 包装: | 広告trivision看板カートンボックス/不織布バッグ |
Tri-vision, Tri-vision Billboard, Tri-vision billboard construction, Billboard structure, Prisma billboard, Advertising billboard, Advertisement billboard, Aluminium prism billboard, Advertising sign, two sided billboard, Rotating panel billboard, Three message billboard
Product Description
Features of Slide-in Tri-vision billboard:
No need for glue or selfadhesive foil. With SLIDE-IN, replacing Trivision posters
could not be easier. Within ten minutes, an entire Trivision sign measuring 60 square
meters / 650 square feet can be fitted with new slide-in graphics. And, double-sided
slide-in graphics can be reversed quickly and easily.
Advantage:
1. Complete in-house production and only using the best materials
2. Trivision signs in lengths up to 300 mtr.
3. The SHG technology guarantees many years of smooth functioning. In any climate! Do you require an extremely large format? Only SHG offers a reliable solution.
Specifications:
Item | Specification |
Motor | 120W original Panasonic Motor,. |
Control System | GK100-B, full automatic controller |
Driving system | Double bevel gear driving system |
Power | 220V/50HZ, 0.54A |
Primary Material | Eco-friendly aluminum alloy, Anti-rust, Anti-corrosion, Shock resistance, Heat resisting |
Driving Component | PA66 Industrial Nylon and Cordura (America Dupont), superior mechanical strength, rigidity, tenacity, shock absorption and abrasive resistance. |
Triangular Prism | Wideness: 60-126mm, Thickness: 1.0-2.0mm |
Dimension | The height is suggested within 8m, no length limit. |
Image Flipping Time | 4-12 seconds ( for your choice) |
Image Stop Time | Freely set from 0-900 seconds. |
Flipping Performance | Opening, closing, wave type, from left to right, from right to left, flipping from part to part |
Wind Resistance | No less than 10 class with automatic wind resistance function, |
Life Span | Proper installation will ensure normal service life up to 10 years based on 16 running hours each day. |
Net Weight | 20kg/sqm |
Packing | Carton box/woven bag |
Application | Airport, Highways, City Centers, Commercial Centers, Outdoor Advertising. |
Sample Trivision in Workshop
Our ServicesGuarantee and After-Sale Service
- Lifetime guarantee for all components and domestic made motor
- One year guarantee for Panasonic Motor
- 24 hours technical support by emails
- calling service
- User-friendly installation
A Reliable and Solid Partner
More than 20 years experience.
Each part of every product is proof of
SHG’s experience and perfectionism. New
designs are developed to ensure that SHG
displays always meet the demands of the time.
