| 原産地: | 中国(本土) | 銘柄: | を三星 | モデル番号: | fd3 | タイプ: | 椅子のメカニズム | 色: | 黒/銀白色 | 材料: | アルミ | のためのストロークアクチュエータ: | オプション | 工場出荷時の型: | 自身の工場、 を訪問する歓迎 | 生産: | カスタム作られた- | moq: | 1pc | スタイル: | 近代的な |
包装
| 包装: | 通常のカートン、 はインナーパッキン、 一般的に4セットカートン。 |
Application:
Sanxing FD3 Linear Actuator is also the Track Linear Actuator, the Track Linear Actuators don’t extend past their total length, these models are ideal for compact applications and projects. Track Actuators are particularly useful for applications wher traditional actuators may be affected by the surrounding environment. You might find track actuators useful in applications such as:
•Furniture and home application
•High-precision appreciation
•Construction machinery
Description:
Sanxing FD3 linear actuators are designed so that no additional space is required other then its total length. Unlike other actuators, the stoke does not extend out of the unit, instead it moves along the track of the unit. This feature allows you to have the same hole-to-hole dimension and fits perfectly in an area wher additional space is not an option. Each FD3 recliner chair linear actuator comes with 2 wires (positive and negative), internal limit switches (non-adjustable) and mounting hole on the motor end. Forces available are 1000N at 30-34mm/s ( no load ) and 5000N at 4-5mm/s ( no load ).
Specifications:
Model | FD3 |
Input voltage | 12V/24V/110VDC |
Load capacity | Max 5000N (push) / 3000N (pull) |
Speed | 4~36mm/s |
Stroke ( S ) | According to customer’s requirement |
Duty cycle | 10% |
Limit switches | Built-in, Factory Preset |
Operation temperature | -20°C~ +40°C |
Noise decibel | ≤48Db |
Protection class | IP20 |
Minimum installation distance ( A ) | 155mm |
Product show:
FD3 Linear Actuator
The actuator is the unit, which converts the operating voltage from the control box into a linear movement.
Welcome to contact us, we will give you our best service, waiting for you! : )
