無電極誘導トンネルランプ中国のサプライヤー-トンネルはつく _トンネルはつく_室外照明_照明・灯具_仕入れ

原産地:	中国(本土)	色温度(CCT):	2700-6500	銘柄:	ゆ
IPの評価:	IP65	光源:	誘導ランプ	モデル番号:	YUA-SD * LJ02
CRI (Ra>):	85	入力電圧(V):	110	ランプの明るい効率(lm/w):	78
認証:	FCC, CCC, RoHS, CE	項目タイプ:	トンネルはつく	働く寿命(時間):	100000
働く温度(℃):	-30 - 50	電源:	80-250ワット	作業周波数:	210 Khz
形状:	長方形	素材:	ダイカストアルミランプシェル	取付高さ:	4-8メートル
品質保証:	5年

包装

包装:	カートンによって外部と合板ケース、泡によって内部。標準出荷梱包

Materail:

1.Lamp body made by high pressure die-casting aluminum, long life and nice appearance.

2. Surface of die-casting aluminum electric box is coated by electrostatic wave, good heat sink effect and long life.

3.imported mirror face reflector, high reflectivity ensure high light luminous output.

4.High strength glass, high light transmission, shockproof.

5.New silicon rubber lock ring, ensure prefect tightness.

Applications:

It suiable for all kinds of building, billboards, square, airport, station, freight yard, tunnel, toll station, plstform, etc, wher is not easy for maintenance of light.

Features of XINYUAO Induction Lamp L

1. Long service life: up to 100,000hrs designed for free maintenance
2. Over 50% energy saving compared to traditional HID lamps
3. High luminous efficacy: 75-85 Lm/W
4. Good color rendering: CRI > 80Ra
5. Fast startup: instant ignition with hot restrike
6. High power factor: > 0.99
7. No flicker: 100~300KHz high working frequency to deliver eye-friendly light
8. Low luminous decay: less than 25% after 60,000hr ignition
9. Wide color temperature range: 2700-6500K
10. Constant power: less than 3% of change at ±10% voltage fluctuation
11. THD < 10%: meet Class L of international standard

1. Long service life: up to 100,000hrs designed for free maintenance

2. Over 50% energy saving compared to traditional HID lamps

3. High luminous efficacy: 75-85 Lm/W

4. Good color rendering: CRI > 80Ra

5. Fast startup: instant ignition with hot restrike

6. High power factor: > 0.99

7. No flicker: 100~300KHz high working frequency to deliver eye-friendly light

8. Low luminous decay: less than 25% after 60,000hr ignition

9. Wide color temperature range: 2700-6500K

10. Constant power: less than 3% of change at ±10% voltage fluctuation

11. THD < 10%: meet Class L of international standard

amp:

Benefit of XINYUAO Induction Lamp Ballast:

1) Electronic circuits feature telecom power technology of BELL Laboratory
2) Resistant to power surge, humidity, corrosion and dust
3) Ultra-wide voltage range: 90V~320V
4) Wider ambient temperature range: -30°C~+50°C
5) PCB board: Component lines tidy and clean
6) Open-circuit and short-circuit protection
7) May repeatedly start up at unstable voltage
8) Anti-lightning design of ballast to absorb instantaneous high voltage
9) State-of-the-art frequency jittering technology ensures EMI/EMC compliance
10) 70% of components imported from abroad to ensure less than 2‰ failure rate

1) Electronic circuits feature telecom power technology of BELL Laboratory

2) Resistant to power surge, humidity, corrosion and dust

3) Ultra-wide voltage range: 90V~320V

4) Wider ambient temperature range: -30°C~+50°C

5) PCB board: Component lines tidy and clean

6) Open-circuit and short-circuit protection

7) May repeatedly start up at unstable voltage

8) Anti-lightning design of ballast to absorb instantaneous high voltage

9) State-of-the-art frequency jittering technology ensures EMI/EMC compliance

10) 70% of components imported from abroad to ensure less than 2‰ failure rate
