| 原産地: | 中国(本土) | 色を出すこと: | 白い | 銘柄: | ads | モデル番号: | ADS-284WF | 入力電圧(V): | dc12 | ランプの明るい効率(lm/w): | 40 | ランプの光束(lm): | 40 | 認証: | CE, RoHS | ランプボディ材料: | プラスチック | ランプ力(W): | 0.96 | 働く寿命(時間): | 50000 | 働く温度(℃): | -40 - 60 | 色温度(CCT): | 純粋な白 | 光源: | LED | IPの評価: | IP66 | 項目タイプ: | 広告はつく | 作業電圧: | dc12v | 作業消費: | 0.. 96ワット | ledタイプ: | smd5050 led | 外形寸法: | 53.8*33.8*5.6ミリメートル | 作業温度: | -40℃-60℃ | ipグレード: | ip66 | 認証: | ce & rohs & sgs | 寿命: | mtbf≥50000hrs | ビーム角(°): | 140 | 保証(年): | 2 |
包装
| 包装: | カートン、 顧客の要求によって決定。 |
High Quality Good Price Led Module
Epistar 3 chips SMD5050 rgb led modules
China good price led module DC12V
4 years experience on Led Module, Led single pixel light and led light strip produce.
CE, RoHS,SGS passed.
Specification:
Working voltage: DC12V
Working consumption: 0.96w
Working temperature: - 40 °C- - 60 °C
Dimension: 53.8*33.8*5.6mm
Led type: SMD5050RGBLED
LED QTY: 4pcs
Lifespan: MTBF≥50000h
Viewing angle: ≥140
Color | Wavelength/color temperature(nm/k) |
Red | 619~635 |
Green | 512~528 |
blue | 463~475 |
Struction:
1. This product is applied to 7~15cm thickness, LOGO Plastic Light Box.
2. SMD LED light with large and uniform emitting angle, no shadow, low thermal resistance, low brightness declines.
3. This module could be linked up to 60 pcs modules, more than 60pcs is strictly prohibited.
4. The diameter of the power cord should be based on the actual maximum current, the product power, cabling length (recommended no more than 6 meters ), and the voltage of the transmission line.
5. Please connect wires following the positive and negative markings on the circuit board.
Applications:
1) Using for the word advertising signs,
2) advertising light box, LED luminous characters,
3) Logo signage backlight
4) light box ,slim light box
5) light for street light
6) channel letter light backlit sign
7) decoration and so on
