| 原産地: | 中国(本土) | LEDの光源: | led | 銘柄: | kaiming | モデル番号: | KP-SB150 | CRI (Ra>): | 80 | 入力電圧(V): | ac100v-240v dc12v/24 ボルト | ランプの明るい効率(lm/w): | 100 | 認証: | CE, RoHS | ランプの光束(lm): | 12000-13500 | ランプボディ材料: | アルミ合金 | ランプ力(W): | 150 | ビーム角(°): | 120 | 働く寿命(時間): | 50000 | 働く温度(℃): | -30 - 50 | 色温度(CCT): | 暖かい白 | IPの評価: | IP65 | 光源: | LED | 項目タイプ: | 高いマストはつく | 素材: | アルミ合金 | 総重量: | 8.2 キログラム | ビーム角: | 120 | ip グレード: | 65 | 周波数範囲: | 50 ｈｚ-60 ｈｚ | 保証: | 3年 | cri: | > 80 | pf: | > 0.95 | 寿命: | > 50000 h | 外形寸法: | 400*184 ミリメートル |
包装
| 包装: | 11pcs/ctn2サイズ23.5*56*60cm3g。 9.4kgw |
| Specifications Description | |
| Input Voltage | AC100V-240V DC12V/24V |
| Frequency Range | 50Hz-60Hz |
| Total Harmonic Distortion | <9% |
| Power Factor | >0.95 |
| Power Efficiency | >88% |
| Working Voltage | DC30-36V |
| LED Quantity | 1PCS |
| Led Consumption | 150W |
| System Consumption | 155W |
| Led Luminous Efficiency | 80-100LM/W |
| LED Initial Flux | >12000LM |
| Lamp Effiency | >91% |
| Average Llluminance | 6M 78.6LUX |
| 8M 35.2LUX | |
| 10M 22LUX | |
| Llluminance Uniformity | >0.6 |
| Color Temperture | 2700-7000K |
| Color Rendering Index | >Ra80 |
| Junction Temperature | <80 degree |
| Working Temperature | _40~50 degree |
| Storage Temperature | _25~65 degree |
| IP Grade | IP60 |
| Net Weight | 8.5KG |
| Working Lifespan | 50000Hs |
Features&Advantage
1. Luminous efficiency :110-120LM / W
2. Long life: LED lamp life of up to 5-7 years;
3. Low heat, no hot-radioactive, no mercury, sodium and other elements harmful to human health;
4. Beneficial to the environment: LED light for all-solid-body impact resistance is not easy broken, waste recycling, pollution-free can be called the "Green Color illumination light source;
5. Adapt to the environment strong: in the -40 -80 °C, humidity ≤ 65% of the environment.
6. 6pcs per carton, carton size: 46x31x26CM , gross weight 9KG
7. Energy saving up to 70-90%;
8. Realistic lighting effect without light distortion.
Quality&Service
1 all our products pass CE and ROHS test .
2 Every products require aging test for 24hours.
3 Each production procedure comply wirh ISO9000
4 Your inquiry will be replied in the shortest time,no more than 24hrs.
5 Any problem aboutthe products will be handle at first-time.
6 Our delivery time is wiyh7-10 days on common quantity.
7 All our products give a warranty of 2 years.
Applications
Roads, streets, parking areas, bridges, highways, expressways, viaducts, intersections, crossroads, villas, campuses, hotel gardens, docks and yacht clubs.
