| 分類: | 実験室のサーモスタット装置 | 原産地: | 中国(本土) | 銘柄: | サミー | モデル番号: | dnp | モード: | dnp | 電力供給: | 220ボルト50 ｈｚ | 消費電力: | ≤150w | 温度範囲: | ルーム温度+ 5〜65℃ | 温度変動: | +-0.5 ℃ | 温度分解能: | 0.1 ℃ | テクニカル指標: | 50l | 温度均一: | +-0.5 ℃ | タイミング範囲: | 1-9999分 | アウトライン薄暗い。: | 350*350*530ミリメートル |
包装
| 包装: | 輸出のための特別な木製のパッケージ。 |
DNP series electrothermal thermostatic incubator
Applicable range
It is the necessary equipment for thermostatic culture in scientific research department like medical service,
medicine,biology,chemical engineering,agriculture,etc.
Feature:
The microcomputer-based intelligent temperature controller is able to display the setting temperature and incubator inner
temperature simultaneously,and can actuate the data storage memory function in case of power supply failure
or machine hung up,after the power is switch on again,it recovers the stored data immediately,In addition,it has
the protections against over temperature,sensor failure,electricity leakage and over current,as well as functions
of timing and audible & visual alarming.
Double-door structure or observation window equipped in the external door is available,the internal bladder is made of
finished stainless steel,and four corners are circular,taking convenience for cleaning.
The heated air circulation system consisting of imported circulating blower and heating pipe keep the incubator
inner temperature uniform.
Through an independent temperature-limit alarming system(optional),the incubator can cut off the power automatically if beyond the limiting temperature,to guarantee the
safety run of experiment and prevent the accident.
Besides above functions,the upgrading LCD intelligent temperature controller adopts the latest PID fuzzy logic
control,which makes temperature control more accurate.RS-485 interface may be configured,it enables the incubator to be connected to the printer or computer,to record
the change of temperature parameters.
Technical parameters.
Mode
Technical Indexes | DNP-9012 (1,A) | DNP-9022 (1,A,E) | DNP-9052 (1,A,E) | DNP-9082 (1,A,E) | DNP-9162 (1,A,E) | DNP-9272 (1,A,E) | |||||
Volume | 16L | 30L | 50L | 80L | 160L | 270L | |||||
Power supply | 220V 50HZ | ||||||||||
Temp range | Room temp +5~65°C | ||||||||||
Temp resolution | 0.1°C | ||||||||||
Temp fluctuation | +-0.5°C | ||||||||||
Temp homogeneity | +-0.5°C | ||||||||||
consumed power | ≤150W | ≤150W | ≤250W | ≤300W | ≤400W | ≤600W | |||||
Size of workroom(mm) | 250*250*250 | 300*280*300 | 350*350*410 | 400*400*500 | 500*500*650 | 600*600*750 | |||||
Outline Dim.(mm) | 350*350*530 | 400*380*580 | 470*440*680 | 520*490*770 | 620*590*920 | 720*690*1020 | |||||
Tming range | 1-9999min | ||||||||||
Shelves(normal) | 2 | 2 | 2 | 2 | 3 | 3 | |||||
Remark | 1:external observation window A:stainless steel internal bladder E: LCD display | ||||||||||
