| 分類: | 実験室のサーモスタット装置 | 原産地: | 中国(本土) | 銘柄: | サミー | モデル番号: | gnp | モード: | gnp | 電力供給: | 220ボルト50 ｈｚ | 加熱モード: | 水ジャケットタイプ | 温度範囲: | ルーム温度+ 5〜65℃ | 温度変動: | +-0.5 ℃ | 温度分解能: | 0.1 ℃ | テクニカル指標: | 50l | 温度均一: | +-0.5 ℃ | タイミング範囲: | 1-9999分 | アウトライン薄暗い。: | 510*480*710ミリメートル |
包装
| 包装: | 輸出のための特別な木製のパッケージ。 |
GNP series waterproof thermostatic incubator
Applicable range
It is the necessary equipment for thermostatic culture in scientific research department like medical service,
medicine,biology,chemical engineering,agriculture,etc.
Feature:
Equipped with stainless steel working chamber,it is made of germproof stainless steel,and designed into
water-jacket structure by argon-arc welding,with long service life.
The microcomputer-based intelligent temperature controller is able to display the setting temperature and incubator inner
temperature simultaneously,and can actuate the data storage memory function in case of power supply failure
or machine hung up,after the power is switched on again,it recovers the stored data immediately,In addition,it
has the protections against over temperature,sensor failure,electricity leakage,over current,over high/low water
level as well as timing function.And,it can stop heating in low water level.
Through an independent temperature-limit alarming system(optional),the incubator can cut off the power automatically if beyond the limiting temperature,to guarantee the
safety run of experiment and prevent the accident.
Double-door structure of observation window equipped in the external door is available,taking very convenient for
observation,without impact on the incubator inner temperature.
Besides above functions,the upgrading LCD intelligent temperature controller has the feature like more
accurate temperature control,maintains the temperature fluctuation of +-0.3°C,RS-485 interface may be equipped,it enables the incubator to be connected to the printer or computer,to
record the change of temperature parameters.
Technical parameters
Mode Technical Indexes | GNP-9050 | GNP-9080 | GNP-9160 | GNP-9270 |
Volume | 50L | 80L | 160L | 270L |
Power supply | 220V 50HZ | |||
Heating mode | water jacket type | |||
Temp range | Room temp +5~65°C | |||
Temp resolution | 0.1°C | |||
Temp fluctuation | +-0.5°C | |||
Temp homogeneity | +-0.5°C | |||
consumed power | 320W | 470W | 620W | 770W |
Size of workroom(mm) | 350*350*400 | 400*400*500 | 500*500*650 | 600*600*750 |
Outline Dim.(mm) | 510*480*710 | 560*530*810 | 660*630*960 | 760*730*1060 |
Timing range | 1-9999min | |||
Shelves(normal) | 2 | 2 | 3 | 3 |
Remark | Note: E represents LCD | |||
