| 分類: | 実験室のサーモスタット装置 | 原産地: | 中国(本土) | 銘柄: | サミー | モデル番号: | dhg | モード: | dhg | 電力供給: | 220ボルト50 ｈｚ | 温度均一: | +-0.5 ℃ | 温度範囲: | ルーム温度+ 10〜250℃ | 温度変動: | +-0.5 ℃ | 温度分解能: | 0.1 ℃ | タイミング範囲: | 1-9999分 | ボリューム: | 30 | 電源: | 500ワット | アウトライン薄暗い。: | 300*300*350ミリメートル |
包装
| 包装: | 輸出のための特別な木製のパッケージ。 |
DHG series electrothermal constant-temperature blast drying box(Hot air sterilizer)
Applicable range
It is applicable to industrial and mining enterprises,control laboratories,scientific research unites and so on,used
for drying,baking,dewaxing,sterilizing,etc.
Feature:
Both the internal and external of box body are made of high quality steel sheet by welding,the surface is
electrostatic spraying treated,internal of workroom is made of finished stainless steel or coated with high
temperature resistant silver paint,the door bears observation window or is of double-door structure,it is novel and elegant in appearance and has advantage of energy saving.
Microcomputer based intelligent digital display temperature controller,it is accurate and reliable in temperature control,it is able to display preset temperature and the actual temperature inside the box synchronously,has alarm functions of over-temperature/heat,electric leakage and sensor failure,also has timing function.
(Intelligent LCD temperature controller is optional)
Adoption of low-noise fan and suitable air channel that form the hot air circulating system,the heated dry air flows through the
objects directly to dry and sterilize.
Besides the above mentioned functions,the upgraded LCD temperature controller also has function of
programmable temperature control,it can be quipped with RS-485 interface that is used to connect it with the recorder and computer for recording the changing conditions of
temperature parameters(optional)
Technical parameters.
Mode Technical Indexes | DHG-9030(A) | DHG-9070(A) | DHG-9140(A) | DHG-9240(A) | |||
Volume | 30L | 70L | 140L | 225L | |||
Power supply | 220V 50HZ | ||||||
power | 500W | 1000W | 1500W | 2000W | |||
Temp range | Room temp +10~250°C | ||||||
Temp resolution | 0.1°C | ||||||
Temp fluctuation | +-0.5°C | ||||||
Temp homogeneity | +-0.5°C | ||||||
Size of workroom(mm) | 300*300*350 | 350*450*450 | 450*550*550 | 500*600*750 | |||
Outline Dim.(mm) | 420*420*620 | 480*520*820 | 580*760*930 | 630*810*1130 | |||
Timing range | 1-9999min | ||||||
Shelves(normal) | 2 | 2 | 2 | 2 | |||
Remark | A: stainless steel internal bladder | ||||||
Mode Technical Indexes | DHG-9023(A) | DHG-9053(A) | DHG-9123(A) | DHG-9203(A) | DHG-9423(A) | DHG-9623(A) | |
Volume | 25L | 53L | 108L | 200L | 430L | 630L | |
Power supply | 220V 50HZ | ||||||
power | 500W | 1000W | 1500W | 2000W | 3000W | 5000W | |
Temp range | Room temp +10~250°C | ||||||
Temp resolution | 0.1°C | ||||||
Temp fluctuation | +-0.5°C | +-1°C | |||||
Temp homogeneity | +-0.5°C | +-1°C | |||||
Size of workroom(mm) | 300*300*275 | 415*370*345 | 554*370*524 | 600*500*600 | 800*600*1000 | 800*600*1300 | |
Outline Dim.(mm) | 570*460*450 | 710*510*540 | 810*540*720 | 720*600*830 | 930*790*1420 | 820*700*1530 | |
Timing range | 1-9999min | ||||||
Shelves(normal) | 2 | 2 | 2 | 3 | 4 | 5 | |
Remark | A: stainless steel internal bladder | ||||||
Mode Technical Indexes | DHG-9202-00(A) | DHG-9101-0(A) DHG-9202-0(A) | DHG-9101-1(A) DHG-9202-1(A) | DHG-9101-2(A) DHG-9202-2(A) | DHG-9101-3(A) DHG-9202-3(A) | ||||
Volume | 16L | 43L | 70L | 140L | 225L | ||||
Power supply | 220V 50HZ | ||||||||
power | 250W | 500W | 1000W | 1500W | 2000W | ||||
Temp range | Room temp +10~300°C | ||||||||
Temp resolution | 0.1°C | ||||||||
Temp fluctuation | +-1°C | ||||||||
Temp homogeneity | +-1°C | ||||||||
Size of workroom(mm) | 250*250*250 | 350*350*350 | 350*450*450 | 450*550*550 | 500*600*750 | ||||
Outline Dim.(mm) | 380*425*560 | 620*500*540 | 480*580*820 | 580*680*920 | 630*730*1120 | ||||
Timing range | 1-9999min | ||||||||
Shelves(normal) | 2 | 2 | 2 | 2 | 2 | ||||
Remark | A: stainless steel internal bladder,temperature fluctuation is +-0.5°C | ||||||||
