| 電圧: | 220 | 原産地: | 中国(本土) | 銘柄: | グローバル | 条件: | 新しい | モデル番号: | Go-1li | 重量: | 5.25kg | 力(W): | 500 | 保証: | 1年間 | 次元(L*W*H): | 200*200*290 | プロダクションレート: | 3l5l7.5l10l | 使用法: | 酸素 | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | 発電機のタイプ: | 12塔 | 酸素メソッドを生成し: | psa | 材料: | ゼオライトまたはリチウム | 酸素純度: | 90+- 5％ | 出口圧力: | 0.06-0.08mpa | 部品: | 酸素ボンベ、 空気圧縮機、 ファン、 チラー | アプリケーション: | 工業用酸素発生器スペアパーツ | 原産地: | 中国広東省( 本土) | パッキング: | 輸出標準パッケージ | のgurantee: | 1年間 |
包装
| 包装: | 輸出標準パッケージ |
Hospital High Quality Oxygen Generator spare parts
**********************************************************************
* 2 or 12 towers oxygen generator spare parts
* PSA lithium/zeolite material
* High oxygen purity
**********************************************************************
Features:
1. Patented products
GO-LI series molecular sieve is an air separation plant which has already obtained domestic patent.
2. Rational construction
Modular construction is the main points of our molecular sieve. Through the different combination of oxygen units, the oxygen output can be from 1 LPM to 160 LPM, even higher.
3. Easy to control
Each unit working seperately, according to the different oxygen output requirement. And free control for the different unit combinations. So that, it can be suitable used for the standardization of products.
4. Stable oxygen output
5. Low-pressure oxygen production working pressure less than 3KG
**********************************************************************
Zeolite material Specifications
Item | Unit | GO-1LI 3 | GO-1LI 5 | GO-1LI 7.5 | GO-1LI 10 |
Oxygen output | LPM | 3 | 5 | 7.5 | 10 |
Oxygen concentration | % | 90%±3% | 90%±3% | 90%±3% | 90%±3% |
Air flow rate | LPM | 36-45 | 60-75 | 90-115 | 150-200 |
Pressure(inlet) | Mpa | 0.14-0.18 | 0.14-0.2 | 0.15-0.21 | 0.18-0.25 |
Pressure(outlet) | Mpa | 0.06-0.08 | 0.06-0.08 | 0.06-0.08 | 0.06-0.08 |
Temperature | °C | indoor temperature | |||
Relative humidity | % | ≤ 70%±10% | |||
Noise | Db | ≤60 | ≤60 | ≤60 | ≤60 |
Dimension | mm | φ200×310 | φ200×430 | φ200×500 | φ200×560 |
Net weight | kg | 5.5 | 7.0 | 8 | 11 |
**********************************************************************
Each capacity in series
**********************************************************************
about US
WHAT WE DO?
We Provide high-quality oxygen generator for:
Oxygen generator wholesalers
Retailers and oneline shops (Ebay, Amazon...)
OEM-The custom-made oxygen generator are available. Upon customer's idea, drawings, photos etc.
ODM-The modification of the oxygen generator after customer's selection is accepted.
Excellent after-sales service:
1 year warranty again the manufacture defect, offer life time consultation on problems occurred.
Report on the making process.
Marketing feedbacks tracing.
**********************************************************************
All of our products are favored and trusted by customers with contemporary design (simplicity, innovation, practicability, multifunction and fashion), convenient operate, durable and its competitive price.
Please don't hesitate to contact with us, you are strongly expecting and welcoming to be the one of our partners in the coming day!
**********************************************************************
Factory & Office
**********************************************************************
Tips:
1. We can supply with Lithium/Zeolite material for oxygen concentrator.
2. We can supply the suitable air compressor, dryer for each different capacity of oxygen concentrator.
3. In order to ensure the stable oxygen capacity and long life time, please use dryer together.
4. If use it for water treatment, please use check valve (we can provide as well) together for preventing water into machine.
