適用:	ポートクレーン	原産地:	中国(本土)	銘柄:	黄金の
モデル番号:	mq6030	スパン:	10月30日	評価される積載量:	0から60トン
最高。 持ち上がる負荷:	60トン	認証:	Iso9001-2000	提供される売り上げ後のサービス:	利用できるエンジニア機械類を海外に整備するため
評価される持ち上がる時:	あなたの設計として	特徴:	門脈クレーン	保証:	12月
条件:	新しい	最高。 持ち上がる高さ:	30メーター

包装

包装:

バルクパッキング

MQ series Portal Crane is the lead of products in ourcorporation. We have nearly 15 years experience to manufacturing this kind crane. Their lifting capacity can be from 5ton to 40ton or more. Their working radius can be changed according to different demands of user. MQ Series Portal Crane is suitable to load and unload cargoes in ports or harbors and cargoes yards. Capable of handing with hook or grab or lifting apreader.

  The jib of 5t,10t,16t Portal Crane is fourfold linkconstrution. The Portal Crane of 40t adopts hor izontal displacement compensator of block and falls of single path as the jib is luffed in and out. The slewing mechanisms offers slewing of 360°. The hoisting, slewing, luffing mechanisms broperated individually or jointly. The luffing mechanism is equipped with two-stage hydraulic brake, eddy current braking and hydraulic damper to reduce the impactive course of luffing and braking.  The slewing support structure of the crane adopts ball dearings type. The driving unit of slewing structure consistsof vertical motor,planetary gear trunk,big gear ring ect. The limit moment coupling against accidental knock when thecrane is slewing.  The crane is equipped with various safety devices and safe work can be ensured.  based on independent development, Through industrial collaboration and new technology introduction. We willmanufacture more superiors this kind of port crane for users and offer the more satisfactory service to coustomers.  MQ Series Portal Crane is designed and manufactured according to following National Standard:GB3811 RULES FOR THE DESIGN OF CRANEGB6067 RULES FOR THE DESIGN OF CRANEGB/T17495 SPECIFICATIONS FOR THE HARBOUR PORTAL CRANE

ModelItem Datum		Unit	MQ530	MQ1033	MQ6030
Hoist Capacity	Hoist Capacity	Ton	5	10	60
	Duty Range	A	A6	A6	A6
	Working Radius	M	8.5-30	9-33	10-30
	Above the Surface of Track	M	25	25	30
	Under the Surface of Track	M	-15	-15	0
Working Speed	Hoist Speed	m/min	70	60	12
	Derricking Speed	m/min	50	50	15
	Slewing Speed	r/min	1.7	1.5	0.4
	Traveling Speed	m/min	25	25	25
Tail Turning Radius		M	7.50	7.68	7.8
Track×Wheel base		M	10.5×10.5	10.5×10.5	10.5×10.5
Max. Wheel base		Kn	185	225	250
Number of Traveling Wheel		Pcs	12	20	32
Number of Driving Wheel		Pcs	8	8	16
Total Mass		Ton	132	220	386
Total Power		Kw	217	330	256



ModelItem Datum		Unit	MQ1633	MQ4030
Hoist Capacity	Hoist Capacity	Ton	16	40
	Duty Range	A	A6	A6
	Working Radius	M	9-33	11-30
	Above the Surface of Track	M	25	25
	Under the Surface of Track	M	-15	-15
Working Speed	Hoist Speed	m/min	50	20
	Derricking Speed	m/min	50	24
	Slewing Speed	r/min	1.5	1.0
	Traveling Speed	m/min	25	25
Tail Turning Radius		M	7.60	7.80
Track×Wheel base		M	10.5×10.5	10.5×10.5
Max. Wheel base		Kn	250	250
Number of Traveling Wheel		Pcs	20	32
Number of Driving Wheel		Pcs	8	16
Total Mass		Ton	275	369
Total Power		Kw	388	346
