| | Model | LG1165 |
|---|
| Specification | Engine Model | SC8D1710G2B1 |
| Rated Power(kW/rpm) | 125/2200 |
| Engine Form | in-line,Six Stroke,Turbocharged |
| Number of Cylinder | 6 |
| Max.Torque(N.m) | 660 |
| Dimension(LxWxH)(mm) | 8800×2670×3500. |
| Operating Weight (Standard)(kg) | 15000 |
| Performance | Travelling Speed(km/h) | Forward | 5,8,12,18,26,32 |
| Reverse | 5,12,26 |
| Traction Force(kN) | 82 |
| Max.Gradeability | 30% |
| Tire inflation Pressure(KPa) | 0.2-0.23 |
| Working Pressure(Mpa) | 16 |
| Transmission Pressure(Mpa) | 1.3-1.7 |
| Operating Specification | Max.Steering Angle of Front Wheels | ±45° |
| Max.Lean Angle of Front Wheels | ±17° |
| Max.Oscillation Angle of Front Wheels | ±15° |
| Max.Oscillation Angle of Balance Box | ±15° |
| Max.Steering Angle of frame | ±23° |
| Min.Tuming Radius Using Articulation(mm) | 8000 |
| Blade | Max.Lift Above Ground(mm) | 455 |
| Max.Depth of Cutting(mm) | 550 |
| Max.Blade Position Angel | 90° |
| Cutting Angle | 34°~65° |
| Circle Reversing Rotation | 360° |
| Moldboard(Width×Height)(mm) | 3665×600 |
| Optional | Front Dozer Blade | |
| Raear Scarifier | |
