| 原産地: | 中国(本土) | 条件: | 新しい |
包装
| 包装: | 標準的なパッキング |
| Items | Unit | Parameters |
|---|---|---|
| Basic paving width | m | 2.5 |
| Max. paving width | m | 6/7 |
| Max. paving thickness | mm | 300 |
| Paving speed | m/min | 2.0~5.98 |
| Travel speed | km/h | 1.52~4.55 |
| Theoretical Productivity | t/h | 400 |
| Hopper Capacity | t | 13 |
| Gradeability | % | 20 |
| Pavement evenness | mm/3m | 3(Asphalt)/5(Stabilized soil) |
| Transverse levelling accuracy | % | 0.02 |
| Engine model | / | YC6108G |
| Engine Parameters | kW/rpm | 92/2300 |
| Fuel tank capacity | L | 160 |
| Machine weight | t | 19.3 |
| Dimension | mm | 6636×2580(3000)×3680 |
| Items | Unit | Parameters | |
|---|---|---|---|
| Screed model | / | 475Q | TVC |
| Type | / | Single vibrator+Gas heating | Single vibrator+Gas heating |
| Extension | / | Hydraulic | Mechanical assembly |
| Width | m | 2.5~6/7 | 3~6/7 |
| Vibrator speed | r/min | 0~1500 | 0~1500 |
| Vibrator amplitude | mm | 4 | 4 |
| Extra-long screed | mm | 625/1125 | 750,500,250 |
