| 原産地: | 中国(本土) | 銘柄: | leadyoのバッテリー | モデル番号: | PCM-L07S25-407 | 基材: | リチウムイオン/ lifepo4 |
包装
| 包装: | ボックス |
6S 22.2V PCM with balance function
| No. | Test item | Criterion | |
| 1 | Voltage | Charging voltage | DC:25.2V CC/CV |
| Balance voltage for single cell | 4.20±0.025V | ||
| 2 | Current | Balance current for single cell | 84±10mA |
| Current consumption for single cell | ≤20μA | ||
| Maximal continuous charging and discharging current | 20A | ||
| 3 | Over-charge Protection | Over charge detection voltage | 4.25±0.025V |
| Over charge detection delay time | 0.7S—1.3S | ||
| Over charge release voltage | 4.05±0.05V | ||
| 4 | Over-discharge Protection | Over discharge detection voltage | 2.50±0.062V |
| Over discharge detection delay time | 14mS—26mS | ||
| Over discharge release voltage | 3.0±0.1V | ||
| 5 | Over-Current Protection | Over current detection voltage | 0.2±0.02V |
| Over current detection current | 100±20A | ||
| Detection delay time | 8ms—16ms | ||
| Release condition | Cut load | ||
| 6 | Short Protection | Detection condition | Exterior short circuit |
| Detection delay time | 200-500us | ||
| Release condition | Cut load | ||
| 7 | Resistance | Protection circuitry(B- to P-) | ≤30mΩ |
| 8 | Temperature | Operating temperature range | -40~+85°C |
| Storage temperature range | -40~+125°C | ||
