| 原産地: | 中国(本土) | 銘柄: | bqc | モデル番号: | Pcbアセンブリ- dl954- bqc | Min.線幅: | 0.075ミリメートル( 3mil) | 基材: | Fr2/fr4/fr5/積層板のグレード | 表面の仕上げ: | Hasl/鉛フリー、 auの浸漬、 ag、 sn、 auめっき | Min.行送り: | 0.075ミリメートル( 3mil) | 板厚さ: | 0.2mm-3.5mm | Min.穴のサイズ: | 0.5mm | 銅の厚さ: | 0.5-3.0oz | 色: | 青 | 証明書: | ul、 iso9001、 rohs指令、 ce | 穴の公差: | Pth: ±0.076、 ntph: ±0.05 | プロファイリングパンチング: | ルーティング、 vカット、 をベベル |
包装
| 包装: | 内部のパッキング: 真空パッケージ外のパッキング: 標準カートン |
Shenzhen BQC Electronic Co. Ltd is a very professional supplier in PCB (printed circuit Board) assembly & manufacture, SMT (surface mounting technology) processing and DIP processing. In order to satisfy the unique needs we are pleasedto supply our clients more EMS (Electronic Mounting Services), including OEM (Original Equipment Manufacturer) & ODM (Original Design Manufacturer)services.
If you are interested in our products or services, please kingly send us your garber file with BOM list.
1. Capacity & Staves
ction |
Position | Capacity | Shift | Manpower | |
SMT | Line 1 | 1.5M/day | Two | 28 | |
Line 2 | 500K/day | Two | |||
Line 3 | 500K/day | Two | |||
DIP | Line 1 | 2,500 pcs/day | One | 18 | |
Line 2 | 2,500 pcs/day | One | |||
Assembly | Line 1 |
| One | 43 | |
& Testing | Line 2 |
| One | ||
QA |
|
|
| 6 | |
Support |
|
|
| 35 |
2. SMT Specialty
|
| PANASONIC | YAMAHA |
PCB Size | Max.: | 510×460(mm2) | 450×330(mm2) |
Min.: | 50×50(mm) | 50×50(mm) | |
PCB Thickness | Max.: | 4 mm | 3.2 mm |
Min.: | 0.3 mm | 0.5 mm | |
Component Dim. |
| 1005 | 201 |
IR Reflow |
| N2 OK | |
What We Had |
| Mother Board | |
Expander Board | |||
Back Plane Board | |||
FPC | |||
Small Board | |||
…. Etc | |||
