| 適用: | Gtaw/tig溶接、 | 動作電流: | 50から160、 | 原産地: | 中国(本土) | 溶接電流: | 40から70、 | 銘柄: | tongchang | モデル番号: | wzr | 長さ: | 150/175 | 材料: | タングステン | 直径: | Dia1.6- 10 | 名: | ジルコニウムタングステン電極 | 他の名前: | カスタマイズされたジルコニウムタングステン電極 | グレード: | wzr8 | 表面: | 磨かれた、 地面 | サイズ: | Dia1.6- 10*150/175 | パッケージ: | 10個 | 色: | 白 |
包装
| 包装: | ジルコニウムタングステン電極パッキング: カートン12.木箱3.クライアントの要求に応じて |
Best quality customized zirconium tungsten electrodes
WZr electrode Zirconiated Tungsten Electrode :
Performance:
Slightly increased life and sparkability due to the addition of 0.8% zirconium oxide.
Balls up easily in AC applications. Handles higher current with less splitting. Improved arc starts and arc stability. Offers minimal tungsten contamination.
Zirconiated Tungsten Electrode :
Zirconiated Tungsten Electrode boasts a fine performance in welding under the condition of AC and has a good anti-corrosiveness. Especially in the case of high load of current, the Zirconium- Tungsten excellent performance is far better than that of other electrodes. When welded ,the end of Zirconiated Tungsten Electrode remains pellet-shaped,reducing the chance of tungsten oozing. It is suitable for welding magnesium, aluminum and their alloy under alternating current.
Designation | Composition | Color Mark | |||
Dioxide | Oxide Compound % | Impurities % | Tungsten % | ||
WZr8h | ZrO2 | 0.0-0.9 0 | ≤0.02 | Remainder | White |
More models available:
1) We can supply electrodes of thoriated tungsten, ceriated tungsten, lanthanated
tungsten, zirconiated tungsten pure tungsten.
2) Item: WP, WT20, WC20, WZr3, WZr8, WL10, WL15, WL20,WY20
3) Diameter: 0.5- 10.0mm
4) Length: 50.00mm, 75.00mm, 150.00mm, 175.00mm, 800-1100MM
5) Quality of surface: polish annealed, or ground annealed
6) Applications: GTAW / TIG welding and plasma welding, cutting
