| ヘッドコード: | ラウンド | 原産地: | 中国(本土) | 形: | 同輩 | 銘柄: | wenxiong | 技術: | 造られる | タイプ: | フランジ | 材料: | ステンレス | 関係: | フランジ | フランジ: | フランジ |
Flange features:
1) Material: stainless steel 304, 304L, 316, 316L
2) Standard: ISO, 3A, DIN, SMS
3) Applications: beer, dairy, beverage and pharmaceutical industries
4) Price: very competitive, especially the price for stainless steel series
5) The specifications can be designed and satisfied for customers' special requirements
| DN | D | C | H | N | M | T | KG |
| 10 | 90 | 60 | 14 | 4 | M12 | 14 | 0.16 |
| 15 | 95 | 65 | 14 | 4 | M12 | 14 | 0.68 |
| 20 | 105 | 75 | 14 | 4 | M12 | 16 | 0.94 |
| 25 | 115 | 85 | 14 | 4 | M12 | 16 | 1.12 |
| 32 | 140 | 100 | 18 | 4 | M16 | 18 | 1.86 |
| 40 | 150 | 110 | 18 | 4 | M16 | 18 | 2.12 |
| 50 | 165 | 125 | 18 | 4 | M16 | 20 | 2.77 |
| 65 | 185 | 145 | 18 | 4 | M16 | 20 | 3.31 |
| 80 | 200 | 160 | 18 | 8 | M16 | 20 | 3.59 |
| 100 | 220 | 180 | 18 | 8 | M16 | 22 | 4.57 |
| 125 | 250 | 210 | 18 | 8 | M16 | 22 | 5.56 |
| 150 | 285 | 240 | 22 | 8 | M20 | 24 | 7.61 |
| 200 | 340 | 295 | 22 | 8 | M20 | 24 | 9.24 |
| 250 | 395 | 350 | 22 | 12 | M20 | 26 | 11.9 |
| 300 | 445 | 400 | 22 | 12 | M20 | 28 | 14.6 |
| 350 | 505 | 460 | 22 | 16 | M20 | 30 | 18.9 |
| 400 | 565 | 515 | 26 | 16 | M24 | 32 | 24.4 |
| 450 | 615 | 565 | 26 | 20 | M24 | 35 | 27.9 |
| 500 | 670 | 620 | 26 | 20 | M24 | 38 | 34.9 |
| 600 | 780 | 725 | 30 | 20 | M24 | 42 | 48.1 |
