| 原産地: | 中国(本土) | 銘柄: | oem | モデル番号: | LX-TPC01 | 最高。 電圧: | 16.8ボルト | 最高。 現在: | 3a (5aはオプション) | 入力電圧: | 3.3ボルト〜16.8ボルト | 動作電流: | 0〜3a (0〜5aはオプション) | ledディスプレイ: | はい | 温度制御: | 三レベル | 水の証拠: | はい | 素材: | シリコーン | アプリケーション: | 加熱された手袋、加熱された服 | 保証: | 一年 | oem/odm: | 利用可能 |
包装
| 包装: | ニュートラルパッケージ |
Battery heated gloves LED switch button, heating gloves LED button
3 Output Level
3.3v ~ 16.8v voltage
0A ~ 3A current (0A ~ 5A is optional)
OEM/ODM service available
Application:
This is a push button which can be sewed into heated gloves/ heated jacket/ heated vest/ heated seat cushion etc., user can press this button to power on, change temperature level and power off.
Specification:
1. Model: L X-TPC01
2. Input Voltage: 3.3-16.8V
3. Output current: 0-3A (0-5A is optional)
4. Operating Efficiency: ≥99%
5. Standby Current: ≤300μA
6. PCB Internal Impedance: <20mΩ
7. Work Temperature: -20~ +60
8. Three output level: red-98%, blue-75%, green-50%.
Working procedure:(With loading & connect to battery pack)1. Press & hold the button for 2 seconds to switch power on, set to 5-minute pre-heat mode at 100% output (during pre-heat mode, also can press button to change heat levels), then go down to medium heat level automatically.2. Press button to change output heat levelsRed - 98% outputBlue - 75% outputGreen - 50% output
Output Power | GREEN LED | BLUE LED | RED LED |
98% | ° | ° | • |
75% | ° | • | ° |
50% | • | ° | ° |
3. Press & hold the button for 2 seconds to switch power off.
Our Advantage:
1) As we are factory, we can guarantee our price is first-hand, very cheap and competitive with high quality.2) To make sure provide customer with high quality product & good service, sample can be sent for approval fristly. Beforeshipment, our QC staff will check quality 1 pc by 1 pc.3) If you receive defective items, please email us photo of the defectives.4) Provide OEM service. Our factory can offer OEM service to customer. Please offer us your LOGO & all OEM design information, and we can do special OEM tooling & OEM service for you.5) After-sale service: all prodcuts are with 1 year warranty. FAQ: Q: 1. Can I have a sample order?A: Of course.
Q: 2. What is the lead time?
A: 3~7 days for sample, 20~25 days for bulk order.
Q: 3. Do you have any MOQ limit?
A: No MOQ for existent items, MOQ 1000pcs for modified ones.
Q: 4. How do you ship the goods and how long does it take arrive?
A: For small quantity, generally ship by DHL, EMS, UPS, or FedEx, usually take 4~7 days to arrive. For large quantity, ship by airplane or ocean, shipping time will depend on destination port.
Q: 5. How to proceed the order if I have logo to print?
A: Firstly MOQ 1000pcs request, then we will prepare artwork for visual /confirm/iation, next we will make a real sample for second /confirm/iation. If sample is ok, finally we will go to mass production.
Q: 6. Do you offer guarantee for the products?
A: Of course, all our products are with One Year Warranty.
