| 出力電圧: | マックスDC40KV | 原産地: | 中国(本土) | 銘柄: | hy | モデル番号: | HY-DY10、HY-DY13、HY-DY20 | 入力電圧: | ac220vまたはac110v | 出力電流: | 28mA-35mA | 出力電力: | 80ワット-180ワット | 色: | ブルー |
包装
| 包装: | 41*28*17カートン |
Reci 80W,100W,150W Laser Tube Power Supply
Model:
HY-DY10 specially for Reci Z2 80W Laser Tube
HY-DY13 specially for Reci Z4 Laser Tube
HY-DY20 specially for Reci Z6, Z8 Laser Tube
HY-HVCO2/0.8 for normal 40W co2 laser tubes
HY-HVCO2/1.2 for normal 60W co2 laser tubes
HY-HVCO2/1.8 for normal 100W co2 laser tubes
HY-HVCO2/2.0 for normal 150W co2 laser tubes
We are factory specialized in all kinds of laser power supply found in 2001, with more than 12 years experience in this field , our products are popularly selling all over the world. Below are features of our products:
1. Main Features:
1).This power supply adopts thin type design The shape of this power supply is thin which is specially designed for special laser tube. The power supply makes laser tube output larger and more stable.
2). Quick Response: It can enlarge laser power and prolong laser tube’s service life.
3). Easy Control: The start and stop of laser can be easily controlled by TTL level.
4). This power supply has output open circuit protection.
5). T This power supply has TTL signal indication, water Through signal indication and laser output indication.
6).This power supply has the BUTTON to test it work properly.
7). Application: Sculpture and cut acrylic, fabric, double color sheet and rubber, etc
2. Main Specification
Type | HY-DY10 | HY-DY13 | HY-DY20 | |
Input | Input voltage | AC220V or AC110V(Please specify when placing order) | ||
AC Frequency | 47---440Hz
| |||
Max Input power | 450W
| 550W
| 1000W
| |
Max Input current | 5A
| 8A
| 10A
| |
Output | Max Output current | 35KV
| 40KV
| 50KV
|
Max Output current | 24mA
| 28mA
| 35mA
| |
Efficiency |
≥90%(Full load) | |||
MTBF | ≥10000 Hours | |||
Response time | ≤1mS(Time from the TTL Signal is given to the output current up to 90% pre-setting current) | |||
Withstand Voltage |
Input-Output, Input-Enclosure: AC1500V 10mA 60S, Output cathode is connected with enclosure. | |||
Environment | Operating temperature: (-10~40)°C,Relative humidity: ≤90% | |||
Cooling | Force-Air Cooling (FAC) | |||
Dimension |
| 78×155×175 | 78×161×247 | 79×200×290 |
Weight |
| 1.75Kg | 2.25 Kg | 2.75 Kg |
Laser power supply parameter
Item | Warranty(month) | Matching laser tube |
DY10 | 12 | 80W W2 |
DY13 | 12 | 100W W4 |
DY20 | 12 | 130W W6 150W W8 |
DY10 80w Laser Power Supply Pictures
For more detail information of our laser power supply or if you need any help, please contact us freely, we will try our best help you.
