| 出力電圧: | 110ボルト/220ボルト | 出力頻度: | 50 ｈｚまたは60 ｈｚ | 原産地: | 中国(本土) |
銘柄: | 必見 | モデル番号: | EA1000 | 入力電圧: | 110ボルト/220ボルト | 色: | 黒または白 | ケース: | プラスチックまたは鉄 | 入力: | 145-290VAc | 機能: | 3ステップavr |
包装
Advanced battery management system with automatic re-charging function.
Special surge suppression output sockets.
Perfect automatic protection against extremely high and low voltage, overload, over-current, short circuit, or low battery.
| MODEL | EA1000-500 | EA1000-650 | EA1000-800 | EA1000-1000 |
| CAPACITY | 500VA/300W | 650VA/390W | 800VA/480W | 1000VA/600W |
| INPUT |
| Voltage | Nominal Voltage | 110/120 VAC or 220/230/240 VAC |
| Acceptable Voltage Range | 90-145 VAC/150-290 VAC |
| Frequency Range | 50 Hz/60HZ |
| OUTPUT |
| AC Voltage Regulation (Batt. Mode) | ±10% |
| Frequency Range (Batt. Mode) | 50 Hz or 60 Hz |
| Transfer Time (Typical) | 2-6 ms |
| Waveform (Batt. Mode) | Modified Sinewave |
| BATTERY |
| Battery Type & Numbers | 12 V 7 Ah x 1 | 12 V 7 Ah x 1 | 12 V 9 Ah x 1 | 12 V 7 Ah x 2 |
| Back up Time(at a PC load | 8 minuters | 10 minuters | 20 minuters | 30 minuters |
| Typical Recharge Time | 10 hours to 90% after complete discharge |
| INDICATORS |
| AC Mode | Green LED lighting |
| Battery Mode | Green LED flashing every 4 seconds |
| Low Battery at Battery Mode | Green LED flashing every second |
| Fault | Red LED lighting |
| Battery Fault at AC modes | Green LED flashing three times every 2 seconds |
| Battery Week at AC modes | Red LED flashing every 2 seconds for 30 seconds |
| Overload | Red LED flashing every twice every second |
| ALARM |
| Battery Mode | Sounding every 4 seconds |
| Low Battery | Sounding every second |
| Fault | Continuously sounding |
| PHYSICAL |
| Dimension, D X W X H (mm) | 295*95*140 |
| Net Weight (kgs) | 5.5 | 6.2 | 6.8 | 10.5 |
| ENVIRONMENT |
| Humidity | 0 to 90% Relative Humidity(Non-condensing) |
| Operating Temperature | 0°Cto 40°C |
