| 出力電圧: | 15KV | 出力頻度: | 50Hzか60Hz | 原産地: | 中国(本土) | 銘柄: | YIYA | モデル番号: | NT-IN | 入力電圧: | 220V | 出力電流: | 30mA | 出力電力: | 450KVA |
包装
| 包装: | カートンが付いているパッケージは、各国のために適している |
Asphalt resin filled and vacuum potted.
Patented magnetic core at low consumption.
metal box and coated power.
User Friendly-Adapts to most grounding situations.
Features:
- Traditional coil and core transformer
- Compact size and light weight
- Asphalt resin filled and vacuum potted
- High reliability and long life
Environmental Specifications :
- Cooling: Convection
Specification:
220V 50Hz 30mA Series Transformer(230V,240V,60Hz is optional)
Vendor's Model Name | Input Voltage(V) | Input Current(A) | Frequency(Hz) | Output Voltage(KV) | Output Current(mA) | Watts (VA) |
NT-1530-IN(220) | 220 | 2.1 | 50 | 15 | 30 | 450 |
NT-1230-IN(220) | 220 | 1.7 | 50 | 12 | 30 | 360 |
NT-0930-IN(220) | 220 | 1.3 | 50 | 9 | 30 | 270 |
NT-7530-IN(220) | 220 | 1.1 | 50 | 7.5 | 30 | 225 |
120V 60Hz Series Transformer | ||||||
NT-1530-IN(120) | 120 | 3.9 | 60 | 15 | 30 | 450 |
NT-1230-IN(120) | 120 | 3.4 | 60 | 12 | 30 | 360 |
NT-0930-IN(120) | 120 | 2.8 | 60 | 9 | 30 | 270 |
NT-7530-IN(120) | 120 | 2.4 | 60 | 7.5 | 30 | 225 |
Remark:Critical specification should be confirmed before placement of order,for further information,please contact with us.
