密封されたタイプ: | 密封される | 維持のタイプ: | 自由 | 電圧: | 12v | 原産地: | 中国(本土) | 銘柄: | jlバッテリー | モデル番号: | NP30-12 12ボルト30ahソーラーバッテリー | 重量: | 10キログラム | サイズ: | l198 * w166 * H175MM | わずかな容量: | 30ああ | 使用法: | ソーラーシステム | 端子タイプ: | リードボルト&内部銅 | oem: | 利用可能 | 色: | ブラック&ホワイト | サンプル: | を送料 | 通常の容量: | 30ああ | モデル番号: | np 30-12 12ボルト30ahソーラーバッテリー | をカスタマイズ: | 許容できる | 予想トリクル生活: | 10-12年 | ケース素材: | abs | 火災の保護標準: | ul94v-0 |
包装
包装: | 2ピースソーラーバッテリー/ 1カートン、を送料燻蒸木製パレットまたはボックス、包装はまた、顧客の要件 |
Product Description
JL solar battery
General features of solar battery
1. Excellent safety performance: No electrolyte leakage, battery swelling and cracking under
normal use.
2. High shock-proof performance: The fully charged and completely fixed battery, with 4mm
amplitude and 16.7HZ frequency do have a normal open circuit voltage without leakage,
batteries swelling or cracking problem after one-hour vibration.
3. High discharging performance: With smooth discharging voltage and mild discharging
platform.
4. High resistance to overdischarge: In temperature of 25 degrees Celsius, the fully charged
battery discharges with fixed resistance which is equivalent to the one required by 1 CA
discharge of the battery for three weeks, and it can restore capacity over 75%.
5. High impact-proof performance: The fully charged battery is proved to maintian normal
open circuit voltage and be without leakage or batteries swelling or cracking after droping
three times from 20cm height naturally to a 1 cm-thick hardwood board.
6. High resistance to high current: The fully charged battery is proved to be without
conductive part melted or any appearance deformation after discharging at 2 CA for
5 minutes or 10 CA for 5 seconds.
7. High resistance to overcharge: The fully charged battery is proved to maintian normal
open circuit voltage and be without leakage or batteries swelling or cracking in temperature
of 25 degrees Celsius after chargeing at 0.1 CA for 48 hours, and the capacity maintian over 95%.
FEATURES AND BENEFITS
6-9 years design life in floating condition
Wide operating temperature range from -15 °C to 50°C
Can be used at vertical or horizontal orientation
Balanced design for both floating and cyclic operation
Low self-discharge rate and long shelf life
CONSTRUCTION
Positive plate – Standard Pb-Ca-Sn alloy
Negative plate – Balanced Pb-Ca grid for improved recombination efficiency
Separator – AGM separator
Electrolyte – Dilute high purity sulphuric acid
Battery container and cover – ABS
Pillar seal – Double layers epoxy resin seal
Relief valve – Self sealing rubber cap valve with proven reliability
ApplicationS
Alarm Systems
Communication Equipments
Control Equipments
Security Systems
Medical Equipments
UPS systems
Power Tools
Toys
Emergency Power Systems
solar battery
Battery Type | Nominal Voltage(V) | 10h rate capacity(ah) | dimension | Weight(kg) | |||
Length | Width | Height | Total height | ||||
12-17 | 12 | 17 | 181 | 76 | 167 | 167 | 5.5 |
12-24 | 12 | 24 | 166 | 125 | 175 | 125 | 8.5 |
12-38 | 12 | 38 | 198 | 166 | 175 | 175 | 13 |
12-65 | 12 | 65 | 350 | 166 | 175 | 175 | 21 |
12-80 | 12 | 90 | 330 | 172 | 238 | 240 | 27 |
12-100 | 12 | 100 | 405 | 175 | 230 | 230 | 30 |
12-120 | 12 | 120 | 405 | 175 | 230 | 230 | 31 |
12-150 | 12 | 150 | 483 | 170 | 239 | 239 | 42 |
12-200 | 12 | 200 | 522 | 240 | 242 | 242 | 55 |
Main Characteristic :
♦ maintenance-Free Operation
Absorbent glass mat (AGM) technology ensures efficient gas recombination up to 99% and freedom from electrolyte maintenance.During the expected float service life of Prostar batteries,no need to check the specific gravity of the electrolyte or add water.
♦ Good Discharging Ability
Tight assembly technology ensures an excellent high-rate discharge performance.
♦ Long Service Life
A unique corrosion-resistant grid alloy ensures Prostar batteries have long service life.
♦ Low Self Discharge
Using high purity raw materials ensures Prostar batteries have less self-discharge.
solar battery
Lead time: 7-10 day after getting payment
Warranty: 2v/12v solar battery have 3 years.
Certificates: ISO, CE, SGS....
Why choose us:
1.door to door service.
2.low cost raw material with high quality.we have own plates factroy, can manufacture plates by ourselves.
3.Independent designer with more than 10 years design experience.
4.product with the international market step.
5.our products are exported to Middle East, Europe, France, Canada, Japan, Korea and else.
6.we would like stand with you in same line to open market with long term business.
