| 原産地: | 中国(本土) | 電圧: | 3.2ボルト | 銘柄: | aet | モデル番号: | 10460320 | 容量: | 81-100 AH | OE NO。: | 10460320 | サイズ: | 10 (t) * 460 (w) * 320 (h) mm | タイプ: | リチウムイオン電池 | 車は作る: | ev、hev、低速モーター | カーバッテリー: | 充電式 |
包装
| 包装: | 標準的な輸出パッケージ; カスタマイズされた。 |
Single cell's capacity and dimension can be CUSTOMIZED!
3.2V 100Ah large capacity for LFP Soft Package battery LFP 10460320 P
Single cell's Technical Specification:
Model No. | LFP10460320P | Standard Charging current | 0.2C |
Weight | ≤2400g | Standard Discharging current | 0.2C |
Nominal capacity | 100Ah | Fast Charging current | 1C |
Nominal voltage | 3.2V | Maximum discharging current | 2C |
Internal resistance | ≤1mΩ | Max. Charge/discharge pulse current(10S) | 4C |
Energy density | ≥150Wh/kg at 0.2DCD | Charging Temperature | 0~45°C |
Discharge cut-off voltage | 2.0V | Discharging Temperature | -20~55°C |
Charge voltage | 3.65V | Cycle Life | 2000 times |
Features:
1. Good cell consistency, High energy density.
2. Low internal resistance, low thermal generated and high safety performance.
3. Good high temperature performance.
4. High capacity, low self-discharge rate and long cycle life.
5. Dimension and type(capacity type and ratio type) can be customized.
Applications:
1. EV: pure electric car, pure electric bus, hybrid electric vehicles, hybrid electric bus, recreational vehicles, chill cars.
2. Storage: solar and wind complementary stored energy streetlights, energy storage systems, household energy storage.
3. Power Supply: communication base station power supply, utility power supply, communication industry, emergency power supply and other system standby power etc.
3.2V20Ah Polymer battery cell LFP1025160P
(Size: Thickness*Width*Height 10*215*160MM)
What we can do:
1. All of our products have proceeded comprehensive testing before shippment;
2. Support imprint your logo on products;
3. OEM orders are warmly welcome!
Warranty and Return:
1. All products have been tested before ship out;
2. All products have 1 year warranty. ( We will Changing or Refunding our products if problems appearanced in 1 year, in the case of correct operation according to the technical specification.)
3. We own the best after-sale service. If any problems happen, our team will do our best to solve for customers.
