High voltage types of fuse cut out
Trunnion
High-strength cast bronze, silver plated. Surfaces around trunnion bear on broad hinge surfaces to keep tube in alignment during closing
Toggle joint
Assures realiable dropout after operation
Trunnion pocket
Secures tube in hingle during closing
onepiece channel
Heavy galvanized steel(which is also used for inserts, hangers, and structural bolts and nuts)
Upper contacts
Silver-to-sliver; stainless-steel spring provides high contact pressure-sure
Standard: ISO9001,IEC,KEMA
Item NO: FSC-1,FSC-2,FSC-3,FSC-4,FSC-5,FSC-6 Series.
MAIN DIMENSIONS AND STANDARD PARTICULARS AS FOLLOW TABLE:
Type | Fig. NO | Rated Voltage (KV) | Rated Current (A) | Breaking Current (A) | Impulse Voltage (BIL) | Power Frequency Withstand Voltage (KV) | Leakage Distance (MM) | Weight (KG) | Dimension (CM) |
FSC-1 | 1 | 15 | 100 | 10000 | 110 | 40 | 250 | 7.3 | 38.5*34.5*10.5 |
FSC-1 | 1 | 15 | 200 | 12000 | 110 | 40 | 250 | 7.3 | 38.5*34.5*10.5 |
FSC-2 | 2 | 15 | 100 | 10000 | 110 | 40 | 250 | 7.5 | 40*34.5*11 |
FSC-2 | 2 | 15 | 200 | 12000 | 110 | 40 | 250 | 7.5 | 40*34.5*11 |
FSC-3 | 3 | 15 | 100 | 10000 | 110 | 40 | 250 | 7.3 | 38.5*34.5*10.5 |
FSC-3 | 3 | 15 | 200 | 12000 | 110 | 40 | 250 | 7.3 | 38.5*34.5*10.5 |
FSC-4 | 4 | 15 | 100 | 8000 | 110 | 40 | 340 | 7.5 | 42*33*11.5 |
FSC-4 | 4 | 15 | 200 | 10000 | 110 | 40 | 340 | 7.5 | 42*33*11.5 |
FSC-5 | 5 | 15 | 100 | 10000 | 110 | 40 | 350 | 3.5 | 42*35*11 |
FSC-5 | 5 | 15 | 200 | 12000 | 110 | 40 | 350 | 3.5 | 42*35*11 |
FSC-6 | 6 | 15 | 100 | 10000 | 110 | 40 | 350 | 3.8 | 42*35*12 |
FSC-6 | 6 | 15 | 200 | 12000 | 110 | 40 | 350 | 3.8 | 42*35*12 |
