Features:
1) Superb reliability due to the adoption of gold contats.
2) Same outline configuration as IC premits auto insertionusing an insertion machine.
3) Washable type has fully sealed construction and permitswashing and steam cleaning cleaning as well, For washingconditions, please consult us.
Applications:
Numerical setting for computer terminal equipment. Price setting for vending machines. Programming for game machines. Programming for industrial equip ment and measuringinstrumnents.
Specifications:
Rating DC24V25mA/50V 100mA
Mechanical Life 100, 000 cycles Min
Contact Resistance 100mΩ MAX
Electrical Life 100, 000 cycles Min
Insulation Resistance 100MΩ MIN
Ambient Temper. Used -25 to 85
Withstand Voltage AC 250V (50-60Hz)1min
Ambient Humidety Used 85% RH
Soldering Temper 260± 5° 5s
Operating Force 0.05-0.6kgf
