| 原産地: | 中国(本土) | コンダクターのサイズ: | >30 AWG | 銘柄: | saipwell | 接触の数: | 11 - 20 | モデル番号: | sp | タイプ: | ねじ | カラー:: | ナチュラル 、 黒、 他の色に カスタマイズ |
包装
| 包装: | 標準的な輸出パッケージ |
Specifications
1. Closed bolt leading hole will not only facilitate operation of screw-rivers, also prevent the bolt from dropping out.
2. Electric potential distribution is realized by either connecting central adapt to the center of terminal or inserting a side adapt to the cone jack.
3. General auxiliaries, such as the end plate, segment spacer, and spacer, are attached for terminal with multiple sections.
4. The insulating shell is made if imported engineering plastic-polyamide Nylon 66(PA66). It is of high mechanical intensity, good and super flexibility.
5. Two ends on the top with white marking system to realize uniformed sign.
high temperature ceramic terminal block
Detailed Information of 3.5mm terminal block
Type: | SP |
Material: | PE, PP, PA |
Galvanized Iron | |
Working Temp: | -40°C - 65°C |
Color: | Natural, Black, other color customized |
Model | 3A-2,5mm2 - 100A-40mm2 |
MOQ | Small orders can be accepted. |
Payment term | A. L/C; T/T (Bank Transfer, Wire Transfer) |
B. Western unio | |
C. Paypal (For Sample Fee & Courier cost) | |
Terms of Payment: FOB Shanghai / Ningbo; CIF, CNF, etc | |
Delivery time | Stock is available. 15-25 working days (Up to your order quantity) for mass production. |
Supply ability | 4×20-feet containers per week. |
Packaging details | A. Common Packing: 10Pcs + Heat Shrink Film + Label + Export Carton |
B. Customized Packing: OEM Label, Inner Box, Blister, etc. | |
HS Code | 8536900000 |
Origin country | Zhejiang, China |
Certification | RoHS, REACH, CE |
high temperature ceramic terminal block
Data Sheet of 3.5mm terminal block
Item no. | Spec. | Length | Width | High | Brass Hole Dia | Screw Size | Plastic | ||
mm | |||||||||
BT011-28 | 3A-4mm2 | 91.4 | 15.6 | 10.8 | 3 | M2.5 x 4 | PE PP PA | ||
BT011-29 | 6A-6mm2 | 112.5 | 15.5 | 12.8 | 3.3 | M3.0 x 5 | PE PP PA | ||
BT011-30 | 10A-10mm2 | 128 | 20.6 | 15 | 4.2 | M3.0 x 6 | PE PP PA | ||
BT011-31 | 15A-12mm2 | 137.3 | 22.5 | 16.6 | 4.5 | M3.5 x 7 | PE PP PA | ||
BT011-32 | 20A-14mm2 | 137.5 | 22.7 | 17.7 | 4.7 | M4.0 x 6.5 | PE PP PA | ||
BT011-33 | 30A-16mm2 | 164.5 | 25.3 | 19 | 5.6 | M4.0 x 7 | PE PP PA | ||
BT011-34 | 60A-25mm2 | 185.5 | 29.2 | 24 | 6.6 | M4.0 x 9 | PE PP PA | ||
BT011-35 | 80A-35mm2 | 204.5 | 32.6 | 27.2 | 7.8 | M5.0 x 11 | PE PP PA | ||
BT011-36 | 100-40mm2 | 250 | 45.6 | 30.6 | 9 | M6.0 x 12 | PE PP PA | ||
high temperature ceramic terminal block
Product Details
high temperature ceramic terminal block
Certified
high temperature ceramic terminal block
If you have any questions ,please contact with me .
