製品情報
| 条件: 新しい | 原産地: 中国(本土) | 銘柄: BeiFangJiChuang |
| モデル番号: xk7150 CNC milling machine | CNCまたはない: CNC |
Item | XK7150 |
Spindle Taper | ISO 50 |
Worktable Size(mm) | 2040×400 |
MAX. Worktable Travel (L/H)(mm) | 1400/460 |
Vertical Worktable Travel (mm) | 500 |
Worktable T-Slot (nunmber/width/distance)(mm) | 3/18/100 |
Swivel Angle of Headstock | ±20° |
Spindle Nose to Worktable surface (mm) | 100---600 |
Spindle Center to Column Guideway (mm) | 560 |
Spindle Speed Range(r.p.m) | 6 steps ,66-960 |
SpindelSleeve Travel(mm) | 100 |
Controlling System | GSK980 /KND-1000M |
Main Motor(Kw) | 11 |
Power Feed Motor(Kw) | 1.5 |
Coolant Pump Motor(w) | 90 |
Range of Table Feed (L,H/V)(mm/min) | 0-4000 |
Speed of Table Rapid Traveling (L,H/V)(m/min) | 8/8/6 |
Overall Dimension(mm) | 2260×3390×2220 |
N.W | 4700kg |
