製品情報
原産地: 中国(本土) | 銘柄: 弘 | モデル番号: Yq-360 |
パワー: 7.5kw | 容量: 6000キロ/h( 石炭)、 4000kg/h9charcoal塵) | ローラーの幅: 250mm |
ローラーの直径: 360ミリメートル | 重量: 1850 | 証明書: ce |
色: カスタマイズされた | 原産地: 河南、 中国 | 納期: 15営業日以内に |
サービス: 高品質 |
包装
包装: 合板ケース |
仕様
宏基炭ボールプレス1.二つのローラー2.さまざまな形である可能性がありproducted3.テーラー- メイドサービス4.良い外観
ホット! 炭/の炭塵ボールプレスによってdirectly 工場売却
アプリケーションの炭ボールプレス機:
Ball press machine useing range: briquette coal production; all kinds of me-tallurgy cold- pellet production。
We can also design and manufacture the ball press of high- pressure and high- strength slag、 that mainly used for the non- ferrous and ferrous me-tal slag of the system、 make the briquette directly go into the furnace smelting quickly、 and increase the added value。 any me-tallurgical industry wastes materials、 accessories take on the furnace、 all require ball press machine。。 for example: dust ash、 pond mud、 oxidation leather、 steel slag、 aluminum ash、 slag、 silico- manganese etc。。
炭ボールpress machine技術的パラメータ:
モデル | Hdxm- 360 | Hdxm- 400 | Hdxm- 500 | |
Production capacity | Hour production | 4 t/h | 8 t/h | 11 t/h |
Annual production | 10、 000 t | 20、 000 t | 30、 000 t | |
Roll width | 250 mm | 280 mm | 300 mm | |
Roll diameter | 360 mm | 400 mm | 500 mm | |
パワー | 7.5 kw | 11- 15 kw | 18.5- 22 kw | |
Spindle speed | 18 r/min | 15 r/min | 13 r/min | |
レデューサ | zq350 | zq400 | zq500 | |
zq400 | zq500 | zq650 | ||
Pressure form | Wedge constant voltage | Wedge constant voltage | Wedge constant voltage | |
Axle base draw bar | Axle base draw bar | Axle base draw bar | ||
Constant voltage and hydraulic interchangeable | Constant voltage and hydraulic interchangeable | Constant voltage and hydraulic interchangeable | ||
Roll material | 65mn | 65mn | 65mn | |
|
| 9cr2mn | ||
alloysteel | alloysteel | alloysteel | ||
Structure form | Biaxial single pressure | Biaxial single pressure | Biaxial single pressure | |
Four shaft double pressure | Four shaft double pressure | Four shaft double pressure | ||
Mainshaft bearing | 319 * 4 | 319 * 4 | 2097724 * 4 | |
Mainshaft | 95 mm | 110 mm | 135 mm | |
45 # steel | 45 # steel | 鍛造 | ||
Briquette size | User defined | User defined | User defined | |
Ex- work price | Usd 3961.33 | Usd 4951.66 | Usd 11883.97 |
生産に特化した ball豆炭プレス機、 石炭ボールプレス、 鉱物粉末ボールプレス、 金属粉ボールプレス、 の石炭の粉ボールプレス、 コークス粉ブリケット。 私たちの工場を所有してい20- 年間経験、 売られている商品、 国内外。 私達の細かいサービスは、 当社foriegnのお客様に受け入れられてきた。
