製品情報
最高圧力: 120のPsi | タイプ: デジタル | 証明: セリウム |
電圧: 12V | 原産地: 中国(本土) | 銘柄: EVERISING |
モデル番号: SP570 | 保証: 12 Months |
包装
包装: 1set/ white box 10 sets/carton |
SP- 570A / B: 6センサー付きバス&トラック用
8センサーと、SP - 580 A / B
リアルタイムは、同時にタイヤの空気圧と温度を監視する。
画面上の6タイヤの表示を示して圧力。
ディスプレイショウどのタイヤが異常である。
強力な機能は、低圧、高圧、漏れ、高温警報を含む。
ビープ音と表示画面の赤色光の点滅とアラーム。
センサーのバッテリーが変更可能である。
バス&トラックのバッテリーを搭載し、ディスプレイ。
警報機能
( 1 )漏れ警報: 48秒0.4Bar以上の圧力低下
( 2 )低圧アラーム:圧力は25%程度の標準よりも低い
( 3 )高圧アラーム:圧力は40%程度の標準よりも高くなる
( 4 )高温警報:タイヤの温度がしきい値を超えている
センサーアラームの( 5 )低消費電力:あらゆるセンサの電源が2.4V以下である
( 6 )無信号アラーム:それは作業を開始した後に25分にわたって一部のセンサ」というメッセージが欠落していない
操作機能
( 1 )圧力単位設定: PSIへの変更バー(予め設定されたユニットは、バーです)
( 2 )温度単位設定: F °するためのC °変化(あらかじめ設定されたユニットは、C °である)
( 3 )標準圧力設定:増減(事前に設定した値は、コールドタイヤ空気圧9バーです)
( 4 )高温アラームしきい値設定:事前に設定された閾値は80 ℃であり、
( 5 )センサーを設定します。センサーを交換する際、新しいセンサーのIDコードを学ぶ
( 6 )為替タイヤ位置:タイヤに不整合センサーは、ディスプレイ上の位置を変更したとき
3 。技術的パラメータ
ディスプレイ
入力電圧: 24 ± 3V
静的通貨: < 6ミリアンペア
動作温度: -40 ° C〜 +85℃
LCD : -30 ° C〜 +80 OC
手術湿度: 5 〜 98パーセント
センサー
圧力範囲: 100kPaの〜 1400Kpa / 1BAR 〜 14Bar
バッテリー寿命: 2年に1.5年
静的通貨: < 0.8μA
オペレーティング·通貨: < 12ミリアンペア
動作温度: -40℃ 〜 125 OC
圧力エラー:は50kPa / ±の0.5Bar ±
読み取り精度温度: 2℃ ±
手術湿度: 5 〜 98パーセント
SP-570A/B: For bus & Truck with 6 sensors
SP-580 A/B with 8 Sensors
Real time monitoring tire pressure and temperature at the same time.
Display show pressure of 6 tires on screen.
Display show which tire is abnormal.
Powerful function includes low pressure, high pressure, leakage, high temperature alarm.
Alarm with beep sound and display screen red light flashing.
Sensor battery is changeable.
Display powered by bus&truck battery.
Alarm Function
(1) Leakage alarm: The pressure decrease over 0.4Bar in 48 seconds
(2) Low pressure alarm: The pressure is lower than standard ab0ut 25%
(3) High Pressure Alarm: The pressure is higher than standard ab0ut 40%
(4) High temperature alarm: The temperature of tire is over the threshold
(5) Low power of sensor alarm: The power of any sensor is less than 2.4v
(6) No signal alarm: Missing some sensors’ message over 25 minutes after it start to work
Operating Functions
(1) Pressure Unit setting: change Bar to PSI (pre-set unit is bar)
(2) Temperature Unit setting : change °C to °F (pre-set unit is °C)
(3) Standard pressure setting: increase or decrease (pre-set value is cold tire pressure 9 Bar)
(4) High temperature alarm threshold setting: pre-set threshold is 80°C
(5) Set up sensor: learn new sensor ID code when replace sensor
(6) Exchange tires position: when mismatch sensor to tires, change position on display
3. Technical Parameter
Display
Input Voltage: 24±3V
Static Currency: <6mA
Operative Temperature: -40°C~+85°C
LCD: -30°C∼+80oC
Operative Humidity: 5∼98%
Sensor
Pressure Range: 100Kpa ~ 1400Kpa / 1Bar ~ 14Bar
Battery Life: 1.5 years to 2years
Static Currency: < 0.8μA
Operating Currency: < 12mA
Operative Temperature: -40oC∼+125oC
Pressure Error: ±50 Kpa / ±0.5Bar
Temperature Reading Accuracy: ±2oC
Operative Humidity: 5∼98%
