製品情報
| 力: W | 電源: 22V | 原産地: 中国(本土) |
| 銘柄: Launch | モデル番号: KWA-300 |
包装
| 包装: full set |
仕様
KWA-300 3D Wheel Alignement 1.Advanced 3D processing 2.Perfect 3D model on the base of kinesiology. 3.Easy operation.
KWA-300 3D Wheel AlignmentSpecificationsKWA-300 3D Wheel Aligner is a precision measurement instrument designed to measure the wheel alignment parameters and compare th KWA-300 3D Wheel Aligner
KWA-300 3D Wheel Aligner is a precision measurement instrument designed to measure the wheel alignment parameters and compare them with the specifications provided by vehicle manufacturer. It also gives instructions to the user for performing corresponding adjustments so as to get the best steering performance and reduce tire wear.
1. Complete test: The can be used to measure the most wheel alignment parameters, such as front wheel toe-in, front wheel camber, caster, Kingpin inclination, maximal steering angle, thrust angle, toe-out on turns, rear wheel toe-in, rear wheel camber, thrust angle, wheelbase difference, tread difference, etc. 2. Brand new 3D computer vision measurement: automatically test the aligning angles with high performance camera. 3. Positive targets: there are any electronic elements inside the targets, and no cables between the targets and the main unit, so the targets are easy to be fastened on the wheel clamps. 4. Provides many kinds of auto test processes and diagram operating interfaces, very simple and clear to operate; the whole test process can be performed automatically, and there are some humanity tips on the corresponding interfaces. 5. Complete databank: wheel alignment data of over 20,000 vehicle models is stored in the system. User can also add new data to the databank. 6. Automatically record the history data, easy for customer measurement. 7. Standard printer to print test result. 8. Provide real-time help with help system. |
Introduction:
KWA-300 3D Wheel Aligner is the latest 3D graphic wheel aligner which can establish movement models and therefore provides full-range aligning service through visual measurement technology.KWA-300 3D Wheel Aligner features complete functionalities, reasonable interface, automatic monitoring and operating tips to eliminate improper operation. The equipment is capable of convenient alignments with real time adjustment of front and rear wheels, and a full range of chassis diagnostic parameters.
Features:
1.Durable target
* Passive target demanding no periodic calibration
* Easy operation and maintenance due to no request for cable connection and battery charging
* Convenient runout compensation procedure with no need for reference
2.Precise Measurement
* Stable light source without shine interface disturbance
* Dynamic compensation measurement
* Real-time display of data makes the adjustment easier
* Flexible measuring modes to give easy access for users of traditional wheel aligners
3.Use Friendly
* Advanced graph processing, mode identification and computer visual technology
* Perfect 3D model on the base of Kinesiology, optical measurement and automotive technology
Specifications:
Item Measurement Range
Total toe-in 0~±40°
Camber 0~±20°
Caster 0~±25°
Kingpin Inclination 0~±25°
Maximal wheelbase it can Measure 4000mm
Requrements on Surroundings:
Ambient temperature: 0~50°C
Relative humidity: ≤85%
Function Improvement
| Item | Notes on Improvement | updat Date |
| KWA-300 V5.00.000 English version | To upgrade software as follow: 1. selec vehicle model: to modify the Database Setting, selec oftendata or normaldata in the system setting environment and it could exchange under the selec vehicle model. In normaldata, it add the function of modify and the result of modify that will save as Customized data but one normaldata only have one Customized data. 2. Rolling Run-out compensation: add the function of lift up compensation, a new button that could enter the lift up compensation, each tire can do run-out compensation and the operation same to the camera calibration. 3. Caster swing: in the system setting environment add the function of kingpin turning operation which contains 20 degrees and 10 degrees, also the kingpin data have two formats interface that could exchange between Graphic formats and Text formats. 4. Front axle: add the function of detailed data,a new button that could enter the interface. 5. Print report: Cancel the save button ,and the function of save and print use the print button, add the second measurement of caster swing, click the button of caster reswing it will do the second measurement 6. OEM Specs: add the function of modify normaldata ,In normaldata, it add the function of modify and the result of modify that will save as Customized data but one normaldata only have one Customized data. 7. Frequent model: add the function of custom user data in the database,after add can be deleted, but it just change state, it could be Data in the database management interface standards 8. System setting: add three modules of select, after selecting save to the installation directory of CONFIG. Ini.File. | 2010-7-6 |
| KWA-300 V4.11.000 English and Chinese Version Issue | Run-out compensation is effective after pushing the vehicle. | 2010-4-22 |
| Change for Cabinet Drawings | Change for Cabinet Drawings | 2010-4-22 |
| KWA300 v4.1(India) | Add quick measurement, addtional measurement, front axle measurement, rear axle measurement etc; KWA-300 V4.1 has similar operation interface and function with X-631. | 2009-12-16 |
| KWA300 V4.1(chinese english version) | Add quick measurement, addtional measurement, front axle measurement, rear axle measurement etc; KWA-300 V4.1 has similar operation interface and function with X-631. | 2009-12-16 |
| KWA-300 Shifting Computer | KWA-300 Start to use DELL computer: 108030036 DELL OptiPlex330,Pentium(R) Dual CPU E430 1.80GHz,SATA 80G,1GB DDR2 SDRAM(includes CD-ROM and English XP OS) DELL can provide better and faster service for end customer from all over the world. | 2009-8-18 |
Spare parts:
| No. | PartCode | PartName |
| 1 | 103201518 | TLT440EW Turntable |
| 2 | 103250180 | Standard clamp 11″-20″ |
| 3 | 103250182 | Middle clamp 11″-25″ |
| 4 | 103202189 | X-631 turntable |
| 5 | 103260187 | Quick clmap |
| 6 | 302010065 | X-631 calibration fra-me |
| 7 | 103250181 | Aluminium kit (standard) |
| 8 | 201013637 | X-531/X-631calibration block assemblly |
| 9 | 103250183 | Large clamp 11″-30″ |
| 10 | 103250186 | Aluminium kit (middle) |
| 11 | 103250192 | Wheel clamp extension |
| 12 | X104090116 | Round adaptor |
